For camping, picnics, and other outdoor activities, a suitable special outdoor camping table can be said to play a very important role. In addition, it can be to facilitating the gathering of people to eat together, but also as a cooking table to support the use. In addition, some design styles can also add a sense of fashion for outdoor activities, so that people can enjoy a pleasant and convenient good time. Here we look at how to test whether the outdoor dining set and chairs meet the standards.
Here is the content:
The seat can not be tilted during the test
Backward stability of seat with backrest
Overall tilt outdoor dining set
Adjustable backrest outdoor dining set with footrest
Adjustable backrest outdoor dining set without legs
Forward stability, all seats
1. Block the lateral feet of the outdoor dining set with a block
2. In the front of the center line of the armrests in the 40mm range of the most unfavorable position downward loading vertical force 350N
3. Load 250N at the position of 100mm from the seat centerline in the direction of the block, the position of the loading force from the backrest. Distance and armrest distance from the backrest of the same
4. Apply a force of 20N outward along the armrest plane, and hold for 5 seconds to see if tipping occurs.
Only for the seat with a backrest height over 50mm
1. Adjust the backrest to the most vertical position of the backrest
2. Block the rear foot of the outdoor dining set with a block
3. Load 600N vertical force at the seat surface loading point
4. In the backrest loading point or the top of the backrest (choose the low point) apply a horizontal backward force F, for 5 seconds to see if it falls over.
This test method only uses the outdoor dining set with θ>=10°, γ between 90° and 170°
1. If the sample has a locking mechanism, the sample should be placed in the most inclined position.
2. Load 11 10kg loading discs on the seat surface, with the loading discs in full contact with the backrest.
3. Check whether the outdoor dining set is tilted over
The test method applies to the sample 10 ° ≤ θ < 55 °, 90 ° ≤ γ ≤ 170 °
1. Adjust the backrest to the lowest position
2. Load 8 loading plates on the backrest through the support device
3. Load 3 loading discs on the resting legs
4. Check whether the outdoor dining set is tipped over
The test method applies to samples 10°≤θ<45°, 90°≤γ≤170°
1. Load 8 loading plates of 10kg on the backrest through the support device
2. Load 3 loading discs at the front end
3. Check whether the outdoor dining set is tipped over
